Max Screen Size 1000*1100 Computer To Screen CTS For Textile Laser Direct Exposure Machine For Decal
CTS laser direct plate making machine is to directly read computer data files and convert them into images, and then expose and image them on the screen by laser projection. This kind of imaging screen is suitable for textile printing, and also suitable for decals, packaging, PCB, 3C Printing on glass covers, etc.
The CTS exposure system simplifies the work process and improves productivity, providing fast and excellent screen exposure with exponentially reduced energy costs, and CTS consumes much less energy. CTS temperature control adaptive technology, save energy costs, reduce screen exposure time and speed up production. It only takes 3 minutes to expose each square meter of the screen, with precise alignment and less labor.
GIS Tech Inc.
GIS Tech is the pioneer in introducing the DLP Technology into the laser imaging applications, owning the whole independent intellectual properties in the technologies of data processing, data transmission, sub-graph, electronic control, board card control, laser and optical lens etc. Our main products are CTS series (Computer to Screen system), CTP (Computer to Plate system) and fully automatic printing plate developing system.
-
| Specification / Model | CTS200 |
| Max screen size ( mm ) | 1000x1100 |
| Min screen size ( mm ) | 400x400 |
| Max exposure size ( mm ) | 900x1000 |
Screen frame thickness
(bespoke service is available) | 25-45mm |
| Imaging System | DMD DLP Technology |
| Emulsion thickness (EOM) | Solvent resistant emulsion 3μm-150μm, water resistant emulsion 3μm- 350μm |
| Exposure time | 120-240s/ ㎡, #350 yellow mesh |
| Resolution | 2540dpi (Optional) |
| Raster | 133LPI |
| Focus system | Fixed focusing |
| File format | 1_bit tiff etc. |
| Laser type | UV laser, wavelength 405±5nm |
| Laser power | 20W/25W(Optional) |
| Equipment size (mm) | 2700x1550x1600 |
| Equipment net weight | 1100KG |
| Conditions | Yellow light room with cleanliness Class 10000, temperature 22±2°C,
40-70% relative humidity (No condensation) |
| Power | Single phase 220v, 50/60HZ, 4KW, gas 1L/min |
High Precision:
Resolutions 2540dpi, with raster 133lpi/dpi (halftones printing)
High Efficiency:
3 minutes to finish the exposure on screen size 1000mm*1000mm. Stencil making efficieny has been greatly improved due to a lot of time is saved by the accurate exposure alignment and lobor reduction.
Low Cost:
Elimination of film positives. Litho film are becoming increasingly expensive and the number of suppliers on the maket is rapidly decreasing. 1 procedure of CTS digital screen making to replace 5 procedures of from the conventional process
